Product DescriptionCompany Info.<>
- Brand:
- Rongjida
- Model:
- GWL-400
- Processing customization:
- Yes
- Types:
- Thermal aging chamber
- Material:
- Stainless steel
- Temperature range:
- -70℃ to +400℃ (Higher temperat ℃
- Power:
- 2.5 W
- Studio size:
- 500×600×500mm mm
- Power source:
- 220V
- Applicable scope:
- It is used in electronics, aut
- Warranty：
- 1 years
I. Product Introduction: The high-temperature aging test chamber is applicable to fields such as electronics, automobiles, aerospace, and material research and development. It is used to simulate the aging process of samples under extreme high-temperature scenarios, expose product defects in advance, and verify reliability. Ii. Technical Parameters Temperature range: -70℃ to +400℃ (Higher temperatures can be customized) Temperature fluctuation: ≤±0.5℃ Temperature uniformity: ≤±2℃ (no-load) Heating rate: 1 to 5℃/min (adjustable, up to 10℃/min at the fastest) Cooling rate: 0.5-3℃/min (depending on the configuration of the refrigeration system) Temperature control method: PID intelligent control + SSR solid state relay Inner box dimensions: Common specifications: 500×600×500mm Shell material: Cold-rolled steel plate with plastic coating (surface anti-oxidation treatment) Inner box material: Stainless steel 304 (SUS304) Heating system: nickel-chromium alloy electric heating wire + air duct circulation Safety protection: Over-temperature alarm, water cut-off protection, leakage protection, motor overload protection Iii. Product Features Inner box: Made of stainless steel 304 material, it is heat-resistant and corrosion-resistant, suitable for high-humidity or corrosive environments. Shell: Cold-rolled steel plate with plastic spraying, surface anti-oxidation treatment, double-layer heat insulation design (filled with aluminosilicate fiber cotton), surface temperature ≤50℃, safe heat insulation. Operation interface: 7-inch color touch screen, supporting multi-segment program programming, data storage and export, convenient and intuitive operation. Multiple protections: Equipped with over-temperature alarm, water cut-off protection, leakage protection and other mechanisms to prevent safety accidents caused by equipment failure. Energy-saving design: Automatically enters low-power standby mode during non-working hours, with dynamic adjustment of heating power to reduce energy consumption. Accelerated aging: Accelerate the aging process of samples through high-temperature environments, shorten the R&D cycle, and reduce testing costs. Flexible customization: Optional humidity modules, gas inlet devices, remote monitoring systems, etc., are available to meet personalized testing requirements.
